What is the Delay Effect? 5 Delay Types Analyzed

What is the Delay Effect? 5 Delay Types Analyzed

- 1 comment

Music production isn’t just about technical knowledge or skill, it’s about expression. You can know every trick in the book about mixing with EQ or using compression, but if the song doesn’t evoke any feeling you’re doing it a disservice. There are several ways to make a mix more expressive. Performing with grit and emotion is the most obvious way, but there are also tools that enhance an instrument’s character, tone, or length. One of the most popular of these tools is the delay effect. There are several types of delay, each with distinct characteristics and applications. Here we’ll go over five of these delay types and how you can use them to make your mix more expressive.

1. Analog/Tape Delay

The earliest delay types in music were pre-digital, born in the budding Rock and Roll era of the 1950s. The primary analog delay device during this time was the tape delay. As the name suggests, these machines used magnetic tape strips to quickly record, playback, and then delete audio sent to it. This resulted in a delay effect which would later be emulated by digital technology. The Echoplex and Roland Space Echo were some of the most used tape delay types of this recording era.

tape delay types

Analog delay types like tape delays are still used by some artists and producers today. Some prefer the vintage authenticity of these sounds, especially for guitar recording. Fortunately, for those who like to keep it simple, companies like Boss and Roland have created digital tape delay effects. These effects mimic with great accuracy the delay sounds created by actual tape delays. There are also tape delay plug-ins present in most DAWs like Logic Pro, and in amp modeler software. All these digital delays essentially do the same thing analog delays do, but more reliably and with easier manipulation.

2. Looping Delay Effect

The digital era made the delay effect usage simpler, more effective, and allowed for even more experimentation. With digital technology, some artists can capture the sound of an entire band all by themselves. This can be achieved by sampling instruments, of course. But for those seeking a more improvisational performance, looping is a helpful tool.

Like any other delay type, looping records the audio being sent to it and plays it back. Unlike other delay types, however, looping doesn’t allow the sound to decay. Rather, it plays the audio back on a continuous loop. This loop can be manually altered, stored, overridden, or deleted. For live performance, multiple loops can be stored and played over one another, allowing just one musician to create several sounds in concert with one another.

looping delay types

The term looping is also used in digital recording. While this is a different type of looping, the idea is similar. A region of time can be highlighted in the DAW, which can then be looped, or played over and over again automatically. This is especially helpful for mixing a particular section or recording several takes via comping.

3. Slapback Echo

This type of delay effect is very quick and punchy, mimicking a natural echo one might hear in a large open room or live setting. In other words, this is a more subtle delay setting that’s great for making guitar and vocals stand out just a bit. In fact, this was used often in the 50s and 60s with artists like Elvis Presley and The Roling Stones. On a standard digital delay pedal, the feedback knob would be turned down quite a bit and the delay time knob turned up. This results in a short burst of delay that’s more of an echo than anything. Slapback echo can even be used for mixing and recording drums to make them sound bigger.

4. Doubling Echo

Doubling echo is very similar to slapback echo in terms of its feedback time, but has a shorter delay time. This results in a doubling effect. It’s a bit like recording the same thing from two different directions and overlaying the resultant tracks. The delay time here is so short the delay is hardly perceived. However, doubling echo can help greatly thicken up a vocal recording, similar to doubling vocals. It’s also often used for recording guitar with a stereo effect. A commonly used doubling echo pedal is TC Electronics’ Mimiq Doubler.

5. Modulated Delay Types: Chorus/Flangers/Phasers

flanger delay types

Sometimes these effects aren’t considered to be delay types, but they indeed derive from delay. However, what makes these effects different from more basic delay options is frequency modulation. To put it simply, a chorus effect takes the initial audio signal, copies it like any other delay effect, and then mixes the resultant sound with the original sound with some alterations in frequency. In other words, the echo you hear won’t be sitting at the same frequency of the input audio. These parameters can be changed with a chorus pedal. For a distinct chorus sound, some people cut off the high and low frequencies and boost the mids. This results in a decay that brings attention to the effect. Chorus effects also split the sound in stereo, widening the signal.

Flange and phase effects differ from chorus effects in a subtle way. Both flangers and phasers continually send the resultant modulated signal back to themselves, resulting in phase shifting that sounds somewhat like a “whoosh.” This occurs because the signal is always moving against itself on the frequency spectrum, canceling and boosting certain frequencies as it echoes. What separates phasers from flangers is simply the type of delay it uses. The former uses phase-based delay while the later uses time-based delay. The effect is similar but different enough technically to warrant different names and pedals. All three of these modulated delay effects can glamorize any song element and add depth to your mix.


Delay is one of the most popular, versatile, and fun tools a producer can work with. For over half a century musicians have been toying around with delay types, and people are still finding new ways to use them creatively. What are some of your favorite delay types and settings?
